Main specification

Product model and name

HLQ5020XLCB Refrigerator truck

Gross weight(Kg)

1875

Drive type

4x2

Payload(Kg)

495

Overall dimension(mm)

4695×1600×2400

Curb weight(Kg)

1250

Cab seats

2

Approach/departure angle(°)

28/28,24/28

Front/rear hang(mm)

895/1100

Axle No.

2

Wheelbase(mm)

2700

Axle load(Kg)

780/1095

Max speed(Km/h)

90

Chassis specification

Chassis model

BJ1020V3JV2-X

Manufacturer

Beiqi Foton Auto Co.,Ltd

Brand name

Foton

Dimension(mm)

4435×1505×1760

Tyre specification

165/70R13LT

Tyre No.

4

Steel spring number

-/5,-/6

Front track base(mm)

1260

Fuel type

Gasoline

Rear track base(mm)

1340

Emission standard

Euro 4

Transmission

5 forward gear,1 reverse gear

Cab

1500 single row, luxurious interiors and seats

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

LJ465Q-2AE

Liuzhou Wuling Liuji Power Co.,Ltd

1051

45(61hp)

Performance

Van body size(mm)

2550*1410*1490

Load capacity(TON)

0.6-1.5T

Lowest refrigeration temperature(℃)

-5℃ to -18℃

Feature and Application

The refrigerator truck is the closed van truck that is used to transport the frozen or fresh goods. This truck is made up of vehicle chassis, Polyurethane insulation van, refrigeration unit and temperature recorder. It is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc. parts can be chosen and installed.
